ماژول سیم کارت لپ تاپ مدل Sierra Wireless AirPrime EM7355

## Product Details & Tech Facts Description The Sierra Wireless EM7455 Embedded Module is an LTE Cat 6 M.2 module that provides LTE, UMTS, and GNSS connectivity for notebook, ultrabook, tablet computers, and M2M applications over 15 different LTE radio frequency bands globally with primary target area Americas and EMEA. The EM7455 will allow a maximum downlink speed of 300 Mbps and a maximum uplink speed of 50 Mbps, including LTE Advanced, with automatic fall back to 3G networks. You might also be interested in Sierra Wireless' newer Cat-7 EM74x1; 11095, Sierra Wireless EM7421 EMEA/APAC 11092, Sierra Wireless EM7411 NAM Form Factor M.2 3042 UMTS Bands B1 (2100) B2 (1900) B3 (1800) B4 (AWS) B5 (850) B8 (900) GNSS technology GPS GLONASS BeiDou Carrier Certification AT&T T-Mobile Verizon US Cellular Sprint Bell Rogers Telus Vodafone Data Interface USB 3.0 USB 2.0 SIM interface Through M.2 connector Dual SIM interface Primary Technology LTE - cat 6 Max DL Speed 300 Mbps GNSS antenna support Passive Active 3.3VDC Operating Temperature Range -40 - 85 °C Voice Call Support No Size 42 x 30 x 2.3 mm LTE Bands B1 (FDD 2100) B2 (FDD 1900) B3 (FDD 1800) B4 (FDD 1700 / AWS) B5 (FDD 850) B7 (FDD 2600) B12 (FDD 700ac) B13 (FDD 700c) B20 (FDD 800DD) B25 (FDD 1900) B26 (FDD 850) B29 (SDL 700) B30 (FDD 2300) B41 (TDD 2500) Max UL Speed 50 Mbps Antenna Connectors IPEX MHF-4 Extended Operating Temperature Range -40 - 85 °C Driver Support Windows 10 Linux Android Windows 8.1 Windows 7 Region Europe North America South America Asia Africa GNSS Yes Certification CE RED CE FCC IC PTCRB GCF NCC ANATEL Chipset Qualcomm MDM9230 FOTA Firmware Updates Yes وضعیت کارکرد: استوک وزن: 5 گرم نوع اتصال: بی‌سیم (Wi-Fi) سایر رابط‌ها: Mini PCI Express M.2 نوع آنتن: دارای سه سوکت جهت اتصال سیم آنتن 3x3 سازگار با سیستم‌ عامل‌های: لینوکسویندوز 7، ویندوز 8، ویندوز 8.1 ، ویندوز 10 . ویندوز 11
